Diameter of the pipeline FS102
|
25 ÷ 250 mm; |
| Diameter of the pipeline FS103 |
100 ÷ 4000 mm; |
| Working pressure |
< 2,5 MPa; 6,3 MPa; |
| Temperature of the liquid |
| standard performance |
(0 ÷ 70)° C; |
| high temperature |
(-10 ÷ 120)° C; |
Ambient temperature
|
| for the secondary transducer |
(-10 ÷ 50)° C; |
| Protection class |
| the primary transducer |
IP68; |
| the secondary transducer |
IP65; |
Power supply
|
| build in accumulator |
10h work; |
| RTC accumulator |
(12÷24) V |
| Materials |
| sensors/ primary transducer |
12X18H9T; |
| electronic unit |
ABS Cover:PC; |
| Грешки |
| FS102 – wet calibration |
< 1%; |
| FS103 – theoretical calibration |
< 1,5%; |
| Display |
2 x 16 LCD, backlight; |
| Outputs – fully opto isolated |
| analog output |
4 ÷ 20 mA; |
|
or 0 ÷ 20 mA; |
|
or 0 ÷ 24 mA; |
| serial port |
RS-485/ RS-232 |
| digital output (Realy)400V/ 0.1A / AC/DC |
≤ 10Hz, 50ms; |
| remote counter |
|
| alarm |
|
| special options |
|
| frequency |
0 ÷ 1 kHz; |
